Kubernetes Logging with Filebeat and Elasticsearch Part 1

in Monitoring and Observability , Containerization

Kubernetes Logging.jpg

This is the first post of a 2 part series where we will set-up production grade Kubernetes logging for applications deployed in the cluster and the cluster itself.


    Introduction

    This is the first post of a 2 part series where we will set-up production grade Kubernetes logging for applications deployed in the cluster and the cluster itself. We will be using Elasticsearch as the logging backend for this. The Elasticsearch setup will be extremely scalable and fault tolerant.

    Deployment Architecture

    Deployment Architecture .jpg
    • Elasticsearch Data Node Pods are deployed as a Stateful Set with a headless service to provide Stable Network Identities.
    • Elasticsearch Master Node Pods are deployed as a Replica Set with a headless service which will help in Auto-discovery.
    • Elasticsearch Client Node Pods are deployed as a Replica Set with an internal service which will allow access to the Data Nodes for R/W requests.
    • Kibana and ElasticHQ Pods are deployed as Replica Sets with Services accessible outside the Kubernetes cluster but still internal to your Subnetwork (not publicly exposed unless otherwise required).
    • HPA (Horizontal Pod Auto-scaler) deployed for Client Nodes to enable auto-scaling under high load.

    ‍

    Important things to keep in mind:

    1. Setting ES_JAVA_OPTS env variable.
    2. Setting CLUSTER_NAME env variable.
    3. Setting NUMBER_OF_MASTERS (to avoid split-brain problem) env variable for master deployment. In case of 3 masters we have set it as 2.
    4. Setting correct Pod-AntiAffinity policies among similar pods in order to ensure HA if a worker node fails.

    Let’s jump right at deploying these services to our GKE cluster.

    ‍

    Deployment and Headless Service for Master Nodes

    Deploy the following manifest to create master nodes and the headless service:

    apiVersion: v1
    kind: Namespace
    metadata:
      name: elasticsearch
    ---
    apiVersion: apps/v1beta1
    kind: Deployment
    metadata:
      name: es-master
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: master
    spec:
      replicas: 3
      template:
        metadata:
          labels:
            component: elasticsearch
            role: master
        spec:
          affinity:
            podAntiAffinity:
              preferredDuringSchedulingIgnoredDuringExecution:
              - weight: 100
                podAffinityTerm:
                  labelSelector:
                    matchExpressions:
                    - key: role
                      operator: In
                      values:
                      - master
                  topologyKey: kubernetes.io/hostname
          initContainers:
          - name: init-sysctl
            image: busybox:1.27.2
            command:
            - sysctl
            - -w
            - vm.max_map_count=262144
            securityContext:
              privileged: true
          containers:
          - name: es-master
            image: quay.io/pires/docker-elasticsearch-kubernetes:6.2.4
            env:
            - name: NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            - name: NODE_NAME
              valueFrom:
                fieldRef:
                  fieldPath: metadata.name
            - name: CLUSTER_NAME
              value: my-es
            - name: NUMBER_OF_MASTERS
              value: "2"
            - name: NODE_MASTER
              value: "true"
            - name: NODE_INGEST
              value: "false"
            - name: NODE_DATA
              value: "false"
            - name: HTTP_ENABLE
              value: "false"
            - name: ES_JAVA_OPTS
              value: -Xms256m -Xmx256m
            - name: PROCESSORS
              valueFrom:
                resourceFieldRef:
                  resource: limits.cpu
            resources:
              limits:
                cpu: 2
            ports:
            - containerPort: 9300
              name: transport
            volumeMounts:
            - name: storage
              mountPath: /data
          volumes:
              - emptyDir:
                  medium: ""
                name: "storage"
    ---
    apiVersion: v1
    kind: Service
    metadata:
      name: elasticsearch-discovery
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: master
    spec:
      selector:
        component: elasticsearch
        role: master
      ports:
      - name: transport
        port: 9300
        protocol: TCP
      clusterIP: None

    If you follow the logs of any of the master-node pods, you will witness the master election among them. This is when the master-node pods choose which one is the leader of the group. When following the logs of the master-nodes, you will also see when new data and client nodes are added.

    root$ kubectl -n elasticsearch logs -f po/es-master-594b58b86c-9jkj2 | grep ClusterApplierService
    [2018-10-21T07:41:54,958][INFO ][o.e.c.s.ClusterApplierService] [es-master-594b58b86c-9jkj2] detected_master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300}, added {{es-master-594b58b86c-lfpps}{wZQmXr5fSfWisCpOHBhaMg}{50jGPeKLSpO9RU_HhnVJCA}{10.9.124.81}{10.9.124.81:9300},{es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300},}, reason: apply cluster state (from master [master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300} committed version [3]])

    It can be seen above that the es-master pod named es-master-594b58b86c-bj7g7 was elected as the leader and the other 2 pods were added to the cluster.

    The headless service named elasticsearch-discovery is set by default as an env variable in the docker image and is used for discovery among the nodes. This can of course be overridden.

    Data Nodes Deployment

    We will use the following manifest to deploy Stateful Set and Headless Service for Data Nodes:

    apiVersion: v1
    kind: Namespace
    metadata:
      name: elasticsearch
    ---
    apiVersion: storage.k8s.io/v1beta1
    kind: StorageClass
    metadata:
      name: fast
    provisioner: kubernetes.io/gce-pd
    parameters:
      type: pd-ssd
      fsType: xfs
    allowVolumeExpansion: true
    ---
    apiVersion: apps/v1beta1
    kind: StatefulSet
    metadata:
      name: es-data
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: data
    spec:
      serviceName: elasticsearch-data
      replicas: 3
      template:
        metadata:
          labels:
            component: elasticsearch
            role: data
        spec:
          affinity:
            podAntiAffinity:
              preferredDuringSchedulingIgnoredDuringExecution:
              - weight: 100
                podAffinityTerm:
                  labelSelector:
                    matchExpressions:
                    - key: role
                      operator: In
                      values:
                      - data
                  topologyKey: kubernetes.io/hostname
          initContainers:
          - name: init-sysctl
            image: busybox:1.27.2
            command:
            - sysctl
            - -w
            - vm.max_map_count=262144
            securityContext:
              privileged: true
          containers:
          - name: es-data
            image: quay.io/pires/docker-elasticsearch-kubernetes:6.2.4
            env:
            - name: NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            - name: NODE_NAME
              valueFrom:
                fieldRef:
                  fieldPath: metadata.name
            - name: CLUSTER_NAME
              value: my-es
            - name: NODE_MASTER
              value: "false"
            - name: NODE_INGEST
              value: "false"
            - name: HTTP_ENABLE
              value: "false"
            - name: ES_JAVA_OPTS
              value: -Xms256m -Xmx256m
            - name: PROCESSORS
              valueFrom:
                resourceFieldRef:
                  resource: limits.cpu
            resources:
              limits:
                cpu: 2
            ports:
            - containerPort: 9300
              name: transport
            volumeMounts:
            - name: storage
              mountPath: /data
      volumeClaimTemplates:
      - metadata:
          name: storage
          annotations:
            volume.beta.kubernetes.io/storage-class: "fast"
        spec:
          accessModes: [ "ReadWriteOnce" ]
          storageClassName: fast
          resources:
            requests:
              storage: 10Gi
    ---
    apiVersion: v1
    kind: Service
    metadata:
      name: elasticsearch-data
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: data
    spec:
      ports:
      - port: 9300
        name: transport
      clusterIP: None
      selector:
        component: elasticsearch
        role: data

    The headless service in the case of data nodes provides stable network identities to the nodes and also helps with the data transfer among them.

    It is important to format the persistent volume before attaching it to the pod. This can be done by specifying the volume type when creating the storage class. We can also set a flag to allow volume expansion on the fly. More can be read about that here.

    ...
    parameters:
     type: pd-ssd
     fsType: xfs
    allowVolumeExpansion: true
    ...

    Client Nodes Deployment

    We will use the following manifest to create the Deployment and External Service for the Client Nodes:

    apiVersion: apps/v1beta1
    kind: Deployment
    metadata:
      name: es-client
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: client
    spec:
      replicas: 2
      template:
        metadata:
          labels:
            component: elasticsearch
            role: client
        spec:
          affinity:
            podAntiAffinity:
              preferredDuringSchedulingIgnoredDuringExecution:
              - weight: 100
                podAffinityTerm:
                  labelSelector:
                    matchExpressions:
                    - key: role
                      operator: In
                      values:
                      - client
                  topologyKey: kubernetes.io/hostname
          initContainers:
          - name: init-sysctl
            image: busybox:1.27.2
            command:
            - sysctl
            - -w
            - vm.max_map_count=262144
            securityContext:
              privileged: true
          containers:
          - name: es-client
            image: quay.io/pires/docker-elasticsearch-kubernetes:6.2.4
            env:
            - name: NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            - name: NODE_NAME
              valueFrom:
                fieldRef:
                  fieldPath: metadata.name
            - name: CLUSTER_NAME
              value: my-es
            - name: NODE_MASTER
              value: "false"
            - name: NODE_DATA
              value: "false"
            - name: HTTP_ENABLE
              value: "true"
            - name: ES_JAVA_OPTS
              value: -Xms256m -Xmx256m
            - name: NETWORK_HOST
              value: _site_,_lo_
            - name: PROCESSORS
              valueFrom:
                resourceFieldRef:
                  resource: limits.cpu
            resources:
              limits:
                cpu: 1
            ports:
            - containerPort: 9200
              name: http
            - containerPort: 9300
              name: transport
            volumeMounts:
            - name: storage
              mountPath: /data
          volumes:
              - emptyDir:
                  medium: ""
                name: storage
    ---
    apiVersion: v1
    kind: Service
    metadata:
      name: elasticsearch
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: client
    spec:
      selector:
        component: elasticsearch
        role: client
      ports:
      - name: http
        port: 9200
      type: LoadBalancer

    The purpose of the service deployed here is to access the ES Cluster from outside the Kubernetes cluster but still internal to our subnet. The annotation “cloud.google.com/load-balancer-type: Internal” ensures this.

    However, if the application reading/writing to our ES cluster is deployed within the cluster then the Elasticsearch service can be accessed by http://elasticsearch.elasticsearch:9200.

    Once all components are deployed we should verify the following:

    ‍

    1. Elasticsearch deployment from inside the Kubernetes cluster using an Ubuntu container.
    root$ kubectl run my-shell --rm -i --tty --image ubuntu -- bash
    root@my-shell-68974bb7f7-pj9x6:/# curl http://elasticsearch.elasticsearch:9200/_cluster/health?pretty
    {
    "cluster_name" : "my-es",
    "status" : "green",
    "timed_out" : false,
    "number_of_nodes" : 7,
    "number_of_data_nodes" : 2,
    "active_primary_shards" : 0,
    "active_shards" : 0,
    "relocating_shards" : 0,
    "initializing_shards" : 0,
    "unassigned_shards" : 0,
    "delayed_unassigned_shards" : 0,
    "number_of_pending_tasks" : 0,
    "number_of_in_flight_fetch" : 0,
    "task_max_waiting_in_queue_millis" : 0,
    "active_shards_percent_as_number" : 100.0
    }
    1. Elasticsearch deployment from outside the cluster using the GCP Internal Load balancer IP (in this case 10.9.120.8). When we check the health using curlhttp://10.9.120.8:9200/_cluster/health?pretty  the output should be the same as above.

    1. Anti-Affinity Rules for our ES-Pods:
    root$ kubectl -n elasticsearch get pods -o wide
    NAME                         READY     STATUS    RESTARTS   AGE       IP            NODE
    es-client-69b84b46d8-kr7j4   1/1       Running   0          10m       10.8.14.52   gke-cluster1-pool1-d2ef2b34-t6h9
    es-client-69b84b46d8-v5pj2   1/1       Running   0          10m       10.8.15.53   gke-cluster1-pool1-42b4fbc4-cncn
    es-data-0                    1/1       Running   0          12m       10.8.16.58   gke-cluster1-pool1-4cfd808c-kpx1
    es-data-1                    1/1       Running   0          12m       10.8.15.52   gke-cluster1-pool1-42b4fbc4-cncn
    es-master-594b58b86c-9jkj2   1/1       Running   0          18m       10.8.15.51   gke-cluster1-pool1-42b4fbc4-cncn
    es-master-594b58b86c-bj7g7   1/1       Running   0          18m       10.8.16.57   gke-cluster1-pool1-4cfd808c-kpx1
    es-master-594b58b86c-lfpps   1/1       Running   0          18m       10.8.14.51   gke-cluster1-pool1-d2ef2b34-t6h9

    Scaling Considerations

    We can deploy auto scalers for our client nodes depending on our CPU thresholds. A sample HPA for client node might look something like this:

    apiVersion: autoscaling/v1
    kind: HorizontalPodAutoscaler
    metadata:
     name: es-client
     namespace: elasticsearch
    spec:
     maxReplicas: 5
     minReplicas: 2
     scaleTargetRef:
       apiVersion: extensions/v1beta1
       kind: Deployment
       name: es-client
    targetCPUUtilizationPercentage: 80

    Whenever the autoscaler kicks in, we can watch the new client-node pods being added to the cluster by observing the logs of any of the master-node pods.

    In case of Data-Node Pods all we have to do is increase the number of replicas using the K8 Dashboard or GKE console. The newly created data node will be automatically added to the cluster and will start replicating data from other nodes.

    Master-Node Pods do not require auto scaling as they only store cluster-state information. In case you want to add more data nodes make sure there is not an even number of master nodes in the cluster. Also, make sure the environment variable NUMBER_OF_MASTERS is updated accordingly.

    #Check logs of es-master leader pod
    root$ kubectl -n elasticsearch logs po/es-master-594b58b86c-bj7g7 | grep ClusterApplierService
    [2018-10-21T07:41:53,731][INFO ][o.e.c.s.ClusterApplierService] [es-master-594b58b86c-bj7g7] new_master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300}, added {{es-master-594b58b86c-lfpps}{wZQmXr5fSfWisCpOHBhaMg}{50jGPeKLSpO9RU_HhnVJCA}{10.9.124.81}{10.9.124.81:9300},}, reason: apply cluster state (from master [master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300} committed version [1] source [zen-disco-elected-as-master ([1] nodes joined)[{es-master-594b58b86c-lfpps}{wZQmXr5fSfWisCpOHBhaMg}{50jGPeKLSpO9RU_HhnVJCA}{10.9.124.81}{10.9.124.81:9300}]]])

    [2018-10-21T07:41:55,162][INFO ][o.e.c.s.ClusterApplierService] [es-master-594b58b86c-bj7g7] added {{es-master-594b58b86c-9jkj2}{x9Prp1VbTq6_kALQVNwIWg}{7NHUSVpuS0mFDTXzAeKRcg}{10.9.125.81}{10.9.125.81:9300},}, reason: apply cluster state (from master [master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300} committed version [3] source [zen-disco-node-join[{es-master-594b58b86c-9jkj2}{x9Prp1VbTq6_kALQVNwIWg}{7NHUSVpuS0mFDTXzAeKRcg}{10.9.125.81}{10.9.125.81:9300}]]])

    [2018-10-21T07:48:02,485][INFO ][o.e.c.s.ClusterApplierService] [es-master-594b58b86c-bj7g7] added {{es-data-0}{SAOhUiLiRkazskZ_TC6EBQ}{qirmfVJBTjSBQtHZnz-QZw}{10.9.126.88}{10.9.126.88:9300},}, reason: apply cluster state (from master [master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300} committed version [4] source [zen-disco-node-join[{es-data-0}{SAOhUiLiRkazskZ_TC6EBQ}{qirmfVJBTjSBQtHZnz-QZw}{10.9.126.88}{10.9.126.88:9300}]]])

    [2018-10-21T07:48:21,984][INFO ][o.e.c.s.ClusterApplierService] [es-master-594b58b86c-bj7g7] added {{es-data-1}{fiv5Wh29TRWGPumm5ypJfA}{EXqKGSzIQquRyWRzxIOWhQ}{10.9.125.82}{10.9.125.82:9300},}, reason: apply cluster state (from master [master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300} committed version [5] source [zen-disco-node-join[{es-data-1}{fiv5Wh29TRWGPumm5ypJfA}{EXqKGSzIQquRyWRzxIOWhQ}{10.9.125.82}{10.9.125.82:9300}]]])

    [2018-10-21T07:50:51,245][INFO ][o.e.c.s.ClusterApplierService] [es-master-594b58b86c-bj7g7] added {{es-client-69b84b46d8-v5pj2}{MMjA_tlTS7ux-UW44i0osg}{rOE4nB_jSmaIQVDZCjP8Rg}{10.9.125.83}{10.9.125.83:9300},}, reason: apply cluster state (from master [master {es-master-594b58b86c-bj7g7}{1aFT97hQQ7yiaBc2CYShBA}{Q3QzlaG3QGazOwtUl7N75Q}{10.9.126.87}{10.9.126.87:9300} committed version [6] source [zen-disco-node-join[{es-client-69b84b46d8-v5pj2}{MMjA_tlTS7ux-UW44i0osg}{rOE4nB_jSmaIQVDZCjP8Rg}{10.9.125.83}{10.9.125.83:9300}]]])

    The logs of the leading master pod clearly depict when each node gets added to the cluster. It is extremely useful in case of debugging issues.

    Deploying Kibana and ES-HQ

    Kibana is a simple tool to visualize ES-data and ES-HQ helps in the administration and monitoring of Elasticsearch clusters. For our Kibana and ES-HQ deployment we keep the following things in mind:

    • We must provide the name of the ES-Cluster as an environment variable to the docker image.
    • The service to access the Kibana/ES-HQ deployment is internal to our organisation only, i.e. No public IP is created. We will need to use a GCP Internal load balancer.

    Kibana Deployment

    We will use the following manifest to create Kibana Deployment and Service:

    apiVersion: apps/v1
    kind: Deployment
    metadata:
      namespace: logging
      name: kibana
      labels:
        component: kibana
    spec:
      replicas: 1
      selector:
        matchLabels:
         component: kibana
      template:
        metadata:
          labels:
            component: kibana
        spec:
          containers:
          - name: kibana
            image: docker.elastic.co/kibana/kibana-oss:6.2.2
            env:
            - name: CLUSTER_NAME
              value: my-es
            - name: ELASTICSEARCH_URL
              value: http://elasticsearch.elasticsearch:9200
            resources:
              limits:
                cpu: 200m
              requests:
                cpu: 100m
            ports:
            - containerPort: 5601
              name: http
    ---
    apiVersion: v1
    kind: Service
    metadata:
      namespace: logging
      name: kibana
      annotations:
        cloud.google.com/load-balancer-type: "Internal"
      labels:
        component: kibana
    spec:
      selector:
        component: kibana
      ports:
      - name: http
        port: 5601
      type: LoadBalancer

    ES-HQ Deployment

    We will use the following manifest to create ES-HQ Deployment and Service:

    apiVersion: apps/v1beta1
    kind: Deployment
    metadata:
      name: es-hq
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: hq
    spec:
      replicas: 1
      template:
        metadata:
          labels:
            component: elasticsearch
            role: hq
        spec:
          containers:
          - name: es-hq
            image: elastichq/elasticsearch-hq:release-v3.4.0
            env:
            - name: HQ_DEFAULT_URL
              value: http://elasticsearch:9200
            resources:
              limits:
                cpu: 0.5
            ports:
            - containerPort: 5000
              name: http
    ---
    apiVersion: v1
    kind: Service
    metadata:
      name: hq
      namespace: elasticsearch
      labels:
        component: elasticsearch
        role: hq
    spec:
      selector:
        component: elasticsearch
        role: hq
      ports:
      - name: http
        port: 5000
      type: LoadBalancer

    We can access both these services using the newly created Internal LoadBalancers.
    Go to http://<External-Ip-Kibana-Service>/app/kibana#/home?_g=()


    Kibana Dashboard:

    Go to http://<External-Ip-ES-Hq-Service>/#!/clusters/my-es

    Elastic HQ.png

    ElasticHQ Dashboard for Cluster Monitoring and Management

    Conclusion

    This concludes deploying ES backend for logging. The Elasticsearch we deployed can be used by other applications as well. The client nodes should scale automatically under high load and data nodes can be added by incrementing the replica count in the statefulset. We will also have to tweak a few env vars but it is fairly straightforward. In the next blog we will learn about deploying a Filebeat DaemonSet in order to send logs to the Elasticsearch backend.

    MetricFire specializes in monitoring time-series, while Elasticsearch dominates the logs monitoring space. Try out the MetricFire product with our free trial to monitor your time-series data, or book a demo and talk to us directly about the monitoring solution that works for you. Stay tuned for part two :)

    This article was written by our guest blogger Vaibhav Thakur. If you liked this article, check out his LinkedIn for more.


    Get similar sotries in your inbox weekly, for free



    Share this story with your friends
    metricfire
    MetricFire

    MetricFire provides a complete infrastructure and application monitoring platform from a suite of open source monitoring tools. Depending on your setup, choose Hosted Prometheus or Graphite and view your metrics on beautiful Grafana dashboards in real-time.
